Nhà Sản phẩmPVC Gabions

Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion Box / Gabion Wall

Chứng nhận
chất lượng tốt Máy mài Gabion giảm giá
We got three machines form KONSON,the machine is good quality and they provide service of installation and debugging.

—— Hassan Fehmi from Turkey

I imported 80,000 sets gabion boxes.The products and marketing team are both excellent.The gabion got a good mark in quality test.

—— Soriane Morchedi from Algeria

Tôi trò chuyện trực tuyến bây giờ

Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion Box / Gabion Wall

Trung Quốc Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion Box / Gabion Wall nhà cung cấp

Hình ảnh lớn :  Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion Box / Gabion Wall

Thông tin chi tiết sản phẩm:

Place of Origin: Jiangsu, China
Hàng hiệu: Konson
Chứng nhận: CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number: KS-PVC-Gabion

Thanh toán:

Minimum Order Quantity: 1000 sqm
Giá bán: Discuss in mail
Packaging Details: weave bag,flat bundle,binding with steel strape or strands,some rolls.as your design.
Delivery Time: 10 days for 1x40 feet FCL
Payment Terms: L/C,T/T
Supply Ability: 12000 sqm per day
Contact Now
Chi tiết sản phẩm

Galvanized Wire Mesh Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion



PVC coated galvanized gabion is the gabion which are woven by the hexagonal mesh, the diameter thickness depends on the mesh size, the diameter is between 2.0mm to 4.0mm if the material is zinc coated, while the diameter will be 3.0mm to 4.5mm if the material is PVC-coated wire, the selvage wire diameter usually is one gauge thicker than the body wire diameter.

PVC coated galvanized gabion specification:

mesh(mm)

wire(mm)

wire(PVC)/inner/outside(mm)

biggest width (mm)

60X80

2.0-2.8

2.0/3.0-2.5/3.5

4300

80X100

2.0-3.2

2.0/3.0-2.8/3.8

4300

80X120

2.0-3.2

2.0/3.0-2.8/3.8

4300

100X120

2.0-3.4

2.0/3.0-2.8/3.8

4300

100X150

2.0-3.4

2.0/3.0-2.8/3.8

4300

120X150

2.0-4.0

2.0/3.0-3.0/4.0

4300



Wire Mesh Fence Hexagonal Mesh PVC Coated Galvanized Gabion Box / Gabion Wall



Retaining walls of all kinds
Embankment constructions
Bridge abutments
As a replacement for concrete gravity walls
Road and rail noise barriers
Soil pressure absorption systems
